Econopipe
A professional and economic pipe cutter. Easy installation. Strong steel structure. Friendly interface, easy opration. Supply with easy and economic software. Flame and plasma options. Portable machine, good for contract based production. Free Pipe Functions. Input existing drawings. Modify drawings easily. Optimize drawing details. Generate G-codes.
Model
ECONOPIPE
Cutting Process
Plasma, Flame
Input voltage(V,Hz)
110/220/230/240,220/380/400/415,50/60
Pipe diameter(mm)
60-315
Pipe length(mm)
3000,6000
Loading capacity(mm,Kg)
3000mm length: Thickness : 15, Weight : 500
CNC controller
Hg 823
Axis
3 axis
Motor
Servo Motor
Positioning accuracy(mm)
±0.5/1000
Repeating accuracy(mm)
±0.2/1000
Positioning speed(mm/min)
6000
Plasma power source
Hypertherm : powermax 45,65,85,105,125
Flame cutting gas
Acetylene, Propane, LPG-02
Nesting software
Free Pipe
